Synthetic Ester Lubricant Base Oil
Trimellitate esters are esters formed by the reaction of trimellitic anhydride with mono alcohol and polyol. It has a high flash point, low volatility, especially suitable for the application of high temperature conditions, can be used as high temperature chain oil base oil, air compressor oil, high and low temperature grease. It can also be used in combination with PAO and high-quality mineral oils, and can be used as a base oil for a variety of fully synthetic or semi-synthetic lubricants.
Trimellitate Ester Base Oil is a synthetic ester base oil series developed for lubricant formulations operating under elevated temperatures, heavy loads, and long service intervals.
Produced from trimellitic anhydride and selected monoalcohols or polyols, trimellitate esters offer a useful balance of high flash point, low volatility, low-temperature fluidity, and thermal stability. The series is available in multiple viscosity grades, allowing lubricant formulators to select a suitable base oil for high-temperature chain oils, air compressor oils, industrial gear oils, and high- or low-temperature grease systems.
The products can also be evaluated in blends with compatible PAO and high-quality mineral base oils. Final blend ratios should be selected according to viscosity targets, additive compatibility, equipment design, and finished-lubricant performance requirements.
| Product name | Kinematic viscosity 40℃ (mm²/s) | Kinematic viscosity 100℃ (mm²/s) | Viscosity index (VI) | Pour point (℃) | Flash point (℃) | Acid Value (mgKOH/g) |
| TM108 | 55-59 | 7.5-8.5 | 110 | -45 | 270 | 0.05 |
| TM118 | 57-60 | 7.5-9.5 | 109 | -47 | 270 | 0.05 |
| TM119 | 80.4 | 9.7 | 99 | -47 | 275 | 0.05 |
| TM100 | 104 | 10.7 | 83 | -42 | 275 | 0.05 |
| TM143 | 143 | 13.1 | 83 | -45 | 280 | 0.05 |
| TM150 | 135-165 | 21-25 | 180 | -35 | 270 | 0.1 |
| TM220 | 198-242 | 27-33 | 180 | -35 | 270 | 0.1 |
| TM220H | 225.2 | 23.02 | 126 | -33 | 250 | 0.1 |
| TM306 | 306 | 20.2 | 73 | -23 | 280 | 0.05 |
| TM320 | 288-352 | 34-43 | 180 | -35 | 270 | 0.1 |
| TM320H | 315.61 | 31.99 | 141 | -33 | 250 | 0.1 |
| TM320B | 320 | 32 | 140 | -35 | 280 | 0.05 |
| TM460 | 414-506 | 48-55 | 180 | -35 | 270 | 0.1 |
| TM500H | 549.25 | 55.74 | 167 | -33 | 250 | 0.1 |
| TM680 | 612-748 | 64-78 | 180 | -35 | 270 | 0.1 |
| TM760H | 760.73 | 77.48 | 183 | -30 | 250 | 0.15 |
| TM2000 | 1800-2200 | 140-155 | 180 | -35 | 270 | 0.1 |
| Application | Recommended Maximum Treat Rate | Typical Use |
|---|---|---|
| High-Temperature Chain Oil | Up to 98% | Chain lubricants for ovens, drying lines, coating lines, textile equipment, and heat-treatment systems |
| Internal Combustion Engine Oil | 5–15% | Ester co-base oil for selected engine oil formulations |
| Air Compressor Oil | Up to 98% | Synthetic compressor oil formulations requiring high flash point and low volatility |
| High- and Low-Temperature Grease | 10–90% | Industrial grease systems requiring viscosity, oil-film retention, and temperature resistance |
| Industrial Gear Oil | Up to 98% | High-viscosity gear oil and heavy-duty industrial lubricant formulations |
Recommended use levels are for formulation reference only. Final treat rates should be confirmed through laboratory testing, additive compatibility evaluation, and finished-product validation.
| Grade Group | Available Grades | Initial Formulation Direction |
|---|---|---|
| Medium Viscosity Grades | TM108, TM118, TM119, TM100, TM120 | Medium-viscosity chain oils, compressor oils, grease base oils, and industrial lubricant blends |
| Medium-High Viscosity Grades | TM143, TM150, TM220, TM220H | High-viscosity compressor oils, industrial gear oils, and grease formulations |
| High Viscosity Grades | TM306, TM320, TM320H, TM320B, TM460 | High-load industrial lubricants, gear oils, and high-temperature grease systems |
| Ultra-High Viscosity Grades | TM500H, TM680, TM760H, TM2000 | Heavy-duty gear oils, high-viscosity greases, and specialized high-temperature lubrication systems |
This guide is for initial selection only. Final grade selection should be based on target finished-oil viscosity, equipment design, operating temperature, additive package, volatility requirements, and application testing.
Trimellitate ester base oil is a synthetic ester lubricant base oil made using trimellitic anhydride and alcohol components. It is commonly considered for high-temperature lubricant formulations requiring high flash point, low volatility, and broad viscosity selection.
Yes. The series can be used at up to 98% in high-temperature chain oil formulations. The final formula should still be verified for volatility, cleanliness, oxidation stability, residue control, and equipment-specific requirements.
Yes. The published application guidance allows use up to 98% in air compressor oil formulations. Grade selection should depend on compressor type, discharge temperature, target viscosity, and finished-lubricant testing requirements.
Yes. It can be evaluated in blends with compatible PAO and selected high-quality mineral base oils. Before commercial use, formulators should verify miscibility, viscosity response, additive solubility, seal compatibility, and finished-oil stability.
The appropriate grade depends on the target finished-oil viscosity, operating temperature, load conditions, and additive system. TM220 through TM2000 may be evaluated for higher-viscosity gear oil and grease systems, subject to formulation testing.
Yes. The suggested reference dosage range for high- and low-temperature grease is 10–90%. Final performance should be validated with the selected thickener system and additive package.
High temperature chain oil 98%（Max）
Internal combustion engine oil 5~15%
Air compressor oil 98%(Max.)
High and low temperature grease 10~90%
Industrial gear oil 98%(Max.)
Good purification at high temperature
High flash point,low volatility
Good low temperature performance
High resistance to emulsification
High thermal stability and oxidation stability
Biodegradable
TM108 Prilube1941
TM143 Prilube1938
TM306 Prilube1939
Plastic drum packing, net weight 200kg per barrel.
Store and transport as non-dangerous goods in a cool, dry and ventilated place.
